Description:
The 2.0mm Right-Angled Pin Header is a single-row male connector designed for efficient PCB connections where space constraints necessitate a horizontal orientation. It features a 2.0mm (0.079″) pitch between pins, ensuring compatibility with standard PCB layouts and ideal for applications requiring compact and reliable interconnections. The right-angle configuration facilitates parallel connections to the board surface, optimizing space and routing flexibility in compact electronic assemblies.
Constructed with durable materials, this header provides reliable electrical connections and mechanical stability. Its design supports straightforward soldering onto PCBs, making it ideal for various applications, including prototyping, custom PCBs, and interfacing modules. The pack includes five headers, offering ample components for multiple projects or replacements.
Specifications:
- Number of Pins: 2 to 40 (single row)
- Pin Spacing (Pitch): 2.0mm (0.079″)
- Orientation: Right-Angle
- Row Configuration: Single Row
- Contact Material: Brass or Phosphor Bronze
- Contact Plating: Gold flash over nickel or tin over copper
- Insulator Material: High-Temperature Thermoplastic (UL94V-0)
- Current Rating: 1A
- Voltage Rating: 250V AC
- Operating Temperature Range: -40°C to +105°C
Features:
- Standard 2.0mm pitch compatible with common PCB designs
- Right-angle design for parallel board connections
- Durable construction with various plating options for reliable connections
- High current and voltage ratings suitable for various applications
- Pack of 5 headers for multiple projects
Contents:
- 5 x 2.0mm Right-Angled Pin Headers
