775 12V – 24V Double Ball Bearing High Speed DC Motor

40 people have recently viewed this product!

775 12V – 24V Double Ball Bearing High Speed DC Motor

5 out of 5 based on 1 customer rating
(1 customer review)

The 775 12V – 24V Double Ball Bearing High-Speed DC Motor is a DC motor classified as a 775 DC Motor and works with 12 to 24 VDC.

$40.95

Order Within –

Availability: 41 in stock

All stock is located in Australia.

FREE SHIPPING Worldwide on orders $199+

EXPRESS SHIPPING Available.

SKU: PHI1002580

Description:

The 775 12V – 24V Double Ball Bearing High-Speed DC Motor is a DC motor classified as a 775 DC Motor and works with 12 to 24 VDC.

It is mainly used as a high speed and high torque motor for power tools.



Specifications:

  • Operating Voltage: 12V to 24V DC
  • Operating Current: 1.7A to 4.7A
  • Speed: 10000RPM @ 12V / 20000RPM @ 24V
  • Shaft Length: 16mm
  • Shaft Diameter: 5mm
  • Motor Diameter: 42mm
  • Motor Length: 66.5mm



Contents:

  • 1 x 775 12V – 24V Double Ball Bearing High-Speed DC Motor
Weight 0.342 kg
Dimensions 145 × 45 × 100 mm
