GX16-2 2 Pin Metal Male Female Aviation Plug Connector – Pack of 2

16 people have recently viewed this product!

GX16-2 2 Pin Metal Male Female Aviation Plug Connector – Pack of 2

The GX16-2 2 Pin Metal Male Female Aviation Plug Connector is a robust solution for secure electrical connections in industrial and aviation applications. Its metal construction and threaded coupling provide durability and reliable performance in harsh environments.

$13.95

Order Within –

Availability: 29 in stock

All stock located in Australia.

FREE SHIPPING Worldwide on orders $199+

EXPRESS SHIPPING Available.

SKU: PHI1003217

Description:

The GX16-2 2 Pin Metal Male Female Aviation Plug Connector is a reliable and robust connector set ideal for various electronic applications requiring secure and stable connections. This connector is designed for panel mounting and features a threaded coupling mechanism that ensures a tight and durable connection suitable for use in harsh environments. Commonly used in aviation, industrial equipment, data acquisition systems, and communications, these connectors provide excellent performance and reliability.

Specifications:

  • Connector Type: GX16
  • Pin Configuration: 2 pins
  • Rated Operating Voltage: 250V
  • Current Handling Capacity: 7A
  • Material: Metal
  • Thread Diameter: 16mm
  • Operating Temperature: -40°C to +85°C
  • Environmental Resistance: Waterproof and Airproof
  • Contact Resistance: ≤ 0.005 ohms
  • Insulation Resistance: ≥ 1000 MΩ

Features:

  • Durable metal construction for long-lasting use
  • Threaded coupling for secure connections
  • Easy installation with separate male and female pins
  • Ideal for harsh and demanding environments
  • Widely used in aviation, automotive, communications, and industrial control systems

Contents:

  • 2 x GX16-2 2 Pin Metal Male Female Aviation Plug Connector
Weight 0.034 kg
Dimensions 110 × 70 × 20 mm
