SRD 24VDC SL-C 5 Pin 10A Relay – Pack of 2

42 people have recently viewed this product!

SRD 24VDC SL-C 5 Pin 10A Relay – Pack of 2

This pack of two SRD-24VDC-SL-C 24V DC relays is perfect for switching applications, handling up to 10A at 250VAC or 30VDC. These SPDT relays are compact and durable, ideal for automation systems, control panels, and home appliances.

$13.95

Order Within –

Availability: 28 in stock

All stock located in Australia.

FREE SHIPPING Worldwide on orders $199+

EXPRESS SHIPPING Available.

SKU: PHI1003370

Description:

The SRD-24VDC-SL-C 5 Pin 10A Relay is a reliable and versatile relay designed for a variety of switching applications. Operating on a 24V DC coil, this relay can handle a current of up to 10A at 250VAC or 30VDC. It features a Single Pole Double Throw (SPDT) configuration, making it suitable for controlling multiple circuits. This relay is widely used in automation systems, control panels, and home appliances due to its robust performance and easy integration.

This pack includes two relays, providing essential components for multiple projects or replacements. The SRD-24VDC-SL-C relay is known for its durability and high switching capacity despite its compact size, making it ideal for dense PCB layouts.

Specifications:

  • Coil Voltage: 24V DC
  • Contact Form: SPDT (Single Pole Double Throw)
  • Current Rating: 10A
  • Max Switching Voltage: 250VAC / 30VDC
  • Coil Resistance: 1600Ω
  • Operating Temperature: -40°C to 85°C
  • Dimensions: 19.1mm x 15.5mm x 15.3mm
  • Mounting Type: PCB Mount
  • Number of Pins: 5

Features:

  • High current handling capability (10A)
  • Compact and lightweight design
  • Durable construction for long-lasting performance
  • Easy integration into various electronic projects
  • Reliable switching for both AC and DC loads

Contents:

  • 2 x SRD-24VDC-SL-C 5 Pin 10A Relays
Weight 0.015 kg
Dimensions 70 × 50 × 15 mm
Brand

Type

Contact Configuration

Coil Voltage

Current Rating

Maximum Switching Voltage

,

Coil Resistance

Operating Temperature

Mounting Type

,

Pins

5
