Transistor Pack BC337 – C1815 – 10 Values – Pack of 100

  • Transistor Pack BC337 – C1815 – 10 Values – Pack of 100 02
  • Transistor Pack BC337 – C1815 – 10 Values – Pack of 100 02

Description

This pack of transistors consists of 10 values ranging from BC337 – C1815 all enclosed in TO-92 housing. read more
SKU:
PHI1061851
Category:
Tags:
,
Brand:

Price

$9.95

Quantity

- +

Total

$9.95

0 reviews

10 in stock

- +

Description

This pack of transistors consists of 10 values ranging from BC337 – C1815 all enclosed in TO-92 housing.

The values consist of BC337, BC327, 2N222, 2N2907, 2N3904, 2N3906, S8050, A1015 and C1815 with 10 of each, making a total of 100 transistors.

Specifications

  • BC337 Bipolar NPN Transistor
    • Quantity: 10
    • Voltage: 45V
    • Current: 800mA
    • Frequency: 100MHz
    • Max power dissipation: 625mW
    • Through Hole TO-92
  • BC327 Bipolar PNP Transistor
    • Quantity: 10
    • Voltage: 45V
    • Current: 800mA
    • Frequency: 100MHz
    • Max power dissipation: 625mW
    • Through Hole TO-92
  • 2N2222 Bipolar NPN Transistor
    • Quantity: 10
    • Voltage: 40V
    • Current: 600mA
    • Frequency: 200MHz
    • Max power dissipation: 625mW
    • Through Hole TO-92
  • 2N907 Bipolar PNP Transistor
    • Quantity: 10
    • Voltage: 40V
    • Current: 600mA
    • Frequency: 200MHz
    • Max power dissipation: 625mW
    • Through Hole TO-92
  • 2N3904 Bipolar NPN Transistor
    • Quantity: 10
    • Voltage: 40V
    • Current: 200mA
    • Frequency: 200MHz
    • Max power dissipation: 625mW
    • Through Hole TO-92
  • 2N3906 Bipolar PNP Transistor
    • Quantity: 10
    • Voltage: 40V
    • Current: 200mA
    • Frequency: 200MHz
    • Max power dissipation: 625mW
    • Through Hole TO-92
  • S8050 Bipolar NPN Transistor
    • Quantity: 10
    • Voltage: 25V
    • Current: 500mA
    • Frequency: 100MHz
    • Max power dissipation: 1W
    • Through Hole TO-92
  • S8550 Bipolar PNP Transistor
    • Quantity: 10
    • Voltage: 25V
    • Current: 500mA
    • Frequency: 100MHz
    • Max power dissipation: 1W
    • Through Hole TO-92
  • A1015 Bipolar PNP Transistor
    • Quantity: 10
    • Voltage: 50V
    • Current: 150mA
    • Frequency: 800MHz
    • Max power dissipation: 400mW
    • Through Hole TO-92
  • C1815 Bipolar NPN Transistor
    • Quantity: 10
    • Voltage: 50V
    • Current: 150mA
    • Frequency: 800MHz
    • Max power dissipation: 400mW
    • Through Hole TO-92

Contents

  • 10 x BC337 Transistor
  • 10 x BC327 Transistor
  • 10 x 2N2222 Transistor
  • 10 x 2N2907 Transistor
  • 10 x 2N3904 Transistor
  • 10 x 2N3906 Transistor
  • 10 x S8050 Transistor
  • 10 x S8550 Transistor
  • 10 x A1015 Transistor
  • 10 x C1815 Transistor
