GA12-N20 Metal Gear 3V 200RPM Motor

21 people have recently viewed this product!

GA12-N20 Metal Gear 3V 200RPM Motor

The GA12-N20 Metal Gear 3V 200RPM Motor is a compact, high-torque DC motor designed for precision applications. It features an all-metal gearbox and operates efficiently at 3V, making it ideal for robotics, automation, and small-scale industrial projects.

$17.95

Order Within –

Availability: 30 in stock

All stock located in Australia.

FREE SHIPPING Worldwide on orders $199+

EXPRESS SHIPPING Available.

SKU: PHI1003431

Description:

The GA12-N20 Metal Gear 3V 200RPM Motor is a robust and efficient DC motor designed for various applications including robotics, automation systems, and small-scale industrial projects. This motor is known for its high torque and low RPM, making it ideal for precision tasks that require reliable and consistent motion control. The compact and lightweight design ensures easy integration into a wide range of devices and projects.

Operating at 3V, this motor delivers a consistent speed of 200RPM, providing a good balance between speed and torque. The all-metal gearbox enhances durability and performance, making it suitable for both professional and hobbyist use. This motor’s low power consumption makes it ideal for battery-operated projects.

Specifications:

  • Model: GA12-N20
  • Rated Voltage: 3V DC
  • Revolving Speed (no load): 200RPM
  • Rated Current (no load): 40mA
  • Rated Torque (loaded): 0.17 kg.cm
  • Rated Current (loaded): 50mA
  • Rated RPM (loaded): 160RPM
  • Stall Torque: 1 kg.cm
  • Stall Current: 0.25A
  • Reduction Ratio: 1:50
  • Total Length: 35mm
  • Gear Material: Full Metal
  • Gearbox Size: 9 x 12 x 10mm (L*W*H)
  • Shaft Size: ∅3 x 10mm (D*L)
  • Net Weight: 10g

Features:

  • High torque and low RPM for precision applications
  • Durable full metal gearbox
  • Compact and lightweight design
  • Low noise operation
  • Suitable for various robotic and automation projects

Contents:

  • 1 x GA12-N20 Metal Gear 3V 200RPM Motor
Weight 0.01 kg
Dimensions 70 × 50 × 10 mm
Brand

Type

Voltage

Voltage Type

Current No-Load

Stall Current

Speed No Load

Shaft Length

Shaft Diameter

Body Length

Body Diameter

Stall Torque
